The assembly features metal pan stair treads containing concrete fill, supported by formed steel pan stringers. A guardrail is mounted to the stair structure, consisting of a 2-inch by 1/2-inch flat plate handrail with eased edges and 1/2-inch outside diameter pickets spaced 4 inches on center.
2"x1/2" FLAT PLATE WITH EASED EDGES PICKET 1/2" OUTSIDE DIA. SPACED 4" O.C. 051200.CH 051200.CH BEYOND 055100.PMR 055100.CFT 055100.AMN
