A two-and-one-half-inch concrete topping slab bears on a cross-laminated timber deck positioned adjacent to a hollow structural section steel beam. The cross-laminated timber deck is set at an elevation of thirty-three feet, nine and one-half inches above finished floor, while the adjacent finished floor elevation is thirty-four feet. The assembly includes a standing seam roof assembly above the structural deck.
1' - 8 1/2" 4' - 5 1/2" 6' - 2" 8 1/2" 8 1/2" NO 2-1/2" CONC. TOPPING SLAB ON CLT DECK & BELOW STANDING SEAM ROOF ASSEMBLY EDGE OF CLT DECK BELOW, ADJACENT TO HSS BEAM, S.S.D. F.F. 34'-0" (CLT) 33'-9 1/2" A.F.F.
