A suspended drywall ceiling assembly is braced with a two-and-a-half-inch by twenty-gauge metal stud compression strut spanning to the overhead structure. The main runner consists of a one-and-a-half-inch by sixteen-gauge channel spaced at forty-eight inches on center, supporting seven-eighths-inch by twenty-gauge furring channels spaced at sixteen inches on center. The furring channels are saddle-tied around the main runner using sixteen-gauge wire. A splayed brace wire provides diagonal seismic or lateral bracing at mid-span, secured to the structure with a maximum two-inch offset. The ceiling membrane is finished with five-eighths-inch gypsum board fastened to the framing.
A872 4 A874 4 A874 5 A875 3 CROSS RUNNER, 7/8" X 20 GA. FURRING CHANNELS @ 16" O.C. SADDLE TIED AROUND MAIN RUNNER WITH 16 GA. WIRE. 1 1/2" X 16 GA. MAIN RUNNER @ 48" O.C. 5/8" GYP. BOARD (TYP.) SPLAYED BRACE WIRE FOR CONNECTION TO STRUCTURE SEE MAX. 2" #8 S.M.S. TROUGH STUD FLANGE AND MAIN RUNNER 2 1/2" X 20 GA. METAL STUD COMPRESSION STRUT MAX. 12'-0" X 8'-0" EACH WAY, WITH 45° DIAGONAL BRACING @ MID-SPAN A876 5
