A-DEHSS — Tactile Egress Signage

Architectural · A-DEHSS

Tactile Egress Signage

About this detail

Tactile egress signage configurations detailing dimensions, text placement, and braille locations for exit routes, stairs, and ramps. Each sign measures six inches wide by five inches high with specified corner radii and internal spacing. Text layouts include Exit Route, Exit Stairs Down, Exit Stairs Up, Exit Ramp Down, Exit Ramp Up, and To Exit. Accompanying notes specify CBC compliance requirements and locations for exterior, stair, ramp, and corridor exit doors.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
