An aluminum curtain wall corner mullion forms a ninety-degree outside turn with an Arcadia or equal aluminum break metal finish matching the adjacent curtain wall. Glazing is installed per schedule into the framing pockets. Dimensional layout includes two and one-quarter inch, one-half inch, and six and one-half inch segments totaling nine and one-quarter inches across the profile.
OUTSIDE INSIDE OUTSIDE INSIDE OUTSIDE INSIDE ARCADIA OR EQUAL ALUM BREAK METAL FINISH TO MATCH CURTAIN WALL CORNER MULLION GLAZING PER SCHEDULE EXTERIOR INTERIOR 2 1/4" 1/2" 6 1/2" 9 1/4" 9 1/4" 2 1/4" 1/2" 6 1/2" 90.00° EXTERIOR INTERIOR
