This plan detail shows an elevator door jamb assembly tied into a framed wall partition finished with thin porcelain tile. A ferromagnetic angle and frame clips, installed at three per jamb, secure the frame to the partition structure. A two-way communication system is centered on the wall to maintain ADA clearance requirements. The elevator car doors align with the finished wall boundary according to the door line.
2" 1 1/4" DOORS LINE OF CAR FRAME CLIP (3 PER JAMB) 2-WAY COMMUNICATION SYSTEM CENTERED ON THE WALL TO ALLOW ADA CLEARENCE THIN PORCELAIN TILE 2" FERROMAGNETIC ANGLE WALL PARTITION AS SCHEDULE. SEE PLANS FOR TYPE
