A-DCWHA — Exterior Storefront

Architectural · A-DCWHA

Exterior Storefront

Units: metric
Sheet: A367
Discipline: Architectural

Materials

Aluminum Concrete

Elements

Doors Floors / Slabs Storefronts Waterproofing / Flashing

Text on the drawing

STOREFRONT SILL PROFILE SILL FLASHING CONT. SEALANT EACH SIDE CONCRETE SLAB STOREFRONT DOOR BOTTOM DOOR THRESHOLD CONCRETE SLAB SILL WS3 DOOR SILL WDS3
