An accessible toilet stall layout is defined by minimum clear dimensions and fixture clearances for compliance. A toilet is positioned with a center line spaced seventeen to eighteen inches from the side wall. The stall requires a minimum clear width of five feet and a minimum length of five feet when the door swings inward. A thirty-six-inch minimum length grab bar is mounted on the rear wall or partition. Additional clearance dimensions dictate side wall spacing, door swing arcs, and mounting heights for grab bars.
17"-18" 1'-0" MAX. 2'-0" MIN. 5'-0" MIN. 5'-0" MIN. 2'-10" CLEAR 3'-6" MIN. 1'-0" MIN. 1'-6" MIN. 4" MAX. 2'-0" MIN. 4'-6" MIN. 5'-0" CLEAR TYP. 59" MIN. @ FLOOR MTD. WHEN DOOR SWINGS IN 56" MIN. @ WALL MTD. WHEN DOOR SWINGS IN TOILET PARTITION OR WALL 36" MIN. LENGTH GRAB BAR CL
