An aluminum window system mullion rests on shims above exterior framing and exterior sheathing, with insulated glass installed within the frame. A pre-finished aluminum sill pan matches the exterior aluminum composite metal panels and is installed over a waterproof pan sloped a minimum of 1/4 inch per foot. Backer rod and sealant seal the joint beneath the mullion, while weep holes provide drainage. High temperature water-resistive barrier and self-adhered flashing protect the exterior wall assembly.
EXTERIOR FRAMING AND EXTERIOR SHEATHING PER PLANS SHIM, AS REQUIRED INSULATED GLASS NOTE: ANY PENETRATIONS IN WATER PROOFING MEMBRANE/WRB SHALL BE FULLY SEALED. INTERIOR PRE-FINISHED ALUMINUM SILL PAN TO MATCH ALUMINUM PANEL EXTERIOR SHEATHING ALUMINUM WINDOW SYSTEM MULLION WEEP HOLE BACKER ROD AND SEALANT HIGH TEMPERATURE WRB PRE-FINISHED ALUMINUM COMPOSITE METAL PANEL SELF-ADHERED FLASHING PAN, WATERPROOFING AND TOP OF WALL TO SLOPE MIN. 1/4" PER FOOT
