A-D9NP2 — Interior Wall Penetration Detail

Architectural · A-D9NP2

Interior Wall Penetration Detail

Units: metric
Sheet: RA-M5.0.1
Discipline: Architectural

Elements

Floors / Slabs Partitions Roof / Floor Openings Walls

Text on the drawing

PIPE PIPE SLEEVE 1 2 1. PROVIDE FIRESTOPPING / SEAL PER SPECIFICATIONS. TYPICAL FOR RATED WALLS. 2. ESCUTCHEON, FOR FINISHED INTERIOR WALLS. NOTES: (TYP) NONE 8 INTERIOR WALL PENETRATION DETAIL
