An accessible side reach profile shows a wheelchair user alongside a vertical wall and counter assembly. The maximum allowable reach depth is dimensioned greater than twenty to twenty-five inches maximum. The maximum height to the operable control or counter surface is dimensioned forty-four inches maximum from the finished floor.
