A 4x4x3/16 inch hollow structural section steel tube column is secured at its base by a 5x7x1/4 inch base plate. The assembly is anchored using four 3/8-inch diameter expansion bolts with a 2-inch minimum embedment. The detail serves walls ranging from 4 feet to 7 feet 6 inches in height, spaced at 4 feet on center.
PLAN VIEW 3/16" MAX 7'-6" 05 50 00 STEEL TUBE 4"x 4"x 3/16" @ 4'-0" OC 05 50 00 BASE PLATE 5"x 7"x 1/4" (4) 3/8" Ø EXP BOLTS WITH 2" MIN EMBED FOR TYPICAL INFO, SEE "A" TOP SAME AS 'A' 2" 2" 3" . WALL 4'-0" TO 7'-6" HIGH B
