Wood slats are mounted on aluminum brackets above a utility boot shelf supported by brackets spaced at thirty inches on center. The bench and shelf assembly aligns with the metal locker positioned above a three-and-a-half-inch ceramic tile-faced concrete curb.
METAL LOCKER CERAMIC TILE OVER CONCRETE CURB 3 1/2" BRACKET @ 30" O.C. BENCH MOUNTED ON SUPPORTING BRACKET ALIGN VARIES UTILITY BOOT SHELF 0' - 6 3/8" WOOD SLAT OVER ALUMINUM BRACKET
