A 2x2 aluminum tube and aluminum frame connect to a half-height steel stud wall at the non-hinge side of a door opening. An L4x4x3/8 structural steel angle ties into a 5/8-inch steel plate secured by Hilti Kwik Bolt TZ expansion anchors with a two-and-a-half-inch minimum embedment into the concrete substrate. A six-inch metal runner channel and six-inch metal studs form the partition framing, finished with interior materials sized per the finish plan. Connection plates are fastened with bolts and welded with three-sixteenth-inch fillet welds typical at the structural junctions.
6" METAL STUD INT FINISH- SEE FINISH PLAN HILTI KWIK BOLT TZ ANCHORS, 2 1/2" MIN EMBEDMENT w/ STRUCT 1 1/4" VFY w/ STRUCT 1 1/4" VFY 3/16" TYP. 6" METAL STUD 6" METAL RUNNER CHANNEL L4x4x3/8" 5/8" STEEL PLATE W/ HILTI KWIK BOLD TZ ANCHORS, 2-1/2" EMBEDMENT, TYP ALUMINUM FRAME - SEE SPECIFICATIONS MAGNETIC LOCK- SEE SPECIFICATIONS 2x2 ALUMINUM TUBE
