A-D7FM3 — Door Head

Architectural · A-D7FM3

Door Head

Units: imperial
Sheet: A367
Discipline: Architectural

Materials

Cold-formed Steel Gypsum / Drywall Metal (misc.)Steel

Elements

Doors Facades / Cladding Insulation Storefronts Walls

Text on the drawing

STOREFRONT HEAD PROFILE 5/8" GB ON METAL STUDS PER WALL TYPE STEEL TUBE (REF STRUCT) PREFINISHED BASE TRIM PREFINISHED EDGE COVER TRIM INSULATED- CORE METAL WALL PANELS STOREFRONT DOOR TOP STOREFRONT DOOR HEAD PROFILE HEAD WH3 DOOR HEAD WDH3
