An in-line joint between adjacent tilt-up concrete wall panels features a sealant bead and backer rod installed on both sides and across the top. The joint includes a one-half-inch architectural reveal where noted on elevations. The dashed line indicates the profile of the concrete panel at thickened panel sections.
3/4" 3/4" 3/4" 3/4" 3/4" SEALANT & BACKER ROD BOTH SIDES & ACROSS TOP (TYP.) TILT - UP WALL PANEL (TYP.) 1/2" REVEAL WHERE NOTED ON ELEVATIONS # LINE OF CONCRETE PANEL AT THICKENED PANELS
