Metal pan riser and sub-tread units receive a two-inch concrete fill reinforced with welded wire fabric. The metal pan assembly rests on steel brackets welded or secured to the structural steel stringer. A steel clip angle provides additional structural support at the stringer base. Typical stair nosing is installed at each riser unless noted otherwise, and a sanitary cove is detailed at the floor intersection.
2" 1" 1" 2” CONCRETE FILL WITH WELDED WIRE FABRIC REINFORCING ON MTL PAN (TYP) STEEL STRINGER STEEL CLIP ANGLE STEEL BRACKETS STAIR NOSING (TYP AT EACH RISER UNO) METAL PAN RISER AND SUBTREAD CONC FILL W/ REIF SEE STAIR SECTION OR FLOOR PLAN DIM TYP RISER SANITARY COVE DEPTH TREAD
