A wall-mounted television is housed within a recessed opening framed by 3-5/8-inch metal studs and a metal stud boxed beam at the opening header. The inside faces of the opening feature 5/8-inch plywood backing where millwork occurs. The millwork face aligns flush with the adjacent tile finish. The clear finish opening height is 3 feet 10-1/4 inches with a total rough opening dimension of 4 feet 0-3/4 inches.
CLEAR FINISH OPENING 3' - 10 1/4" WALL MOUNTED TV MILLWORK FACE TO ALIGN WITH TILE FINISH 3-5/8" METAL STUD 5/8" PLYWOOD BACKING AT OPENING INSIDE FACES WHERE MILLWORK OCCURS 3-5/8" METAL STUD SEE PLAN FOR FRAMING TYPE AND SIZE METAL STUD BOXED BEAM AT OPENING 3' - 5 7/8" 4' - 0 3/4" 1' - 4" 8"
