A hollow structural section member connects to a rectangular base plate measuring eight inches by six inches with a one-quarter-inch fillet weld. Four anchor bolts positioned three-quarters of an inch from the edges secure the assembly, spaced one and one-quarter inches typical on center. The plate features a half-inch overhang relative to the underlying framing components.
