A metal stud partition bears on a concrete masonry unit curb with an adjacent hollow metal door frame. The hollow metal frame width matches the stud partition above the curb, secured with flat straps and backing plates. Partition types vary per floor plans and CMU occurs below as required. The door size is nominal and provided as scheduled.
FLAT STRAP AND BACKING PLATE DOOR AS SCHEDULED 4 " 2 " ADJACENT WALL LOCATION, UNO 5 / 8 " NOMINAL DOOR SIZE V A R I E S SEE FLOOR PLANS FOR PARTITION TYPE CMU BELOW AS OCCURS ZA OR ZD PARTITION H.M. FRAME WIDTH TO MATCH STUD PARTITION ABOVE CURB
