Architectural · A-D37WK

Lavatory Vanity and Tile Wainscot Wall Section

Materials

Elements

Walls Partitions Ceilings Floors / Slabs

About this detail

This interior wall section details a daycare restroom lavatory installation featuring a wall-mounted vanity top with an integrated sink over a plastic laminate apron front and sides on a substrate, supported by hidden concealed supports. Above the vanity, a tile wainscot rises to one foot ten inches with tile set in a thin-set mortar bed with one-eighth-inch grout joints and a finishing edge. A custom cloud LED backlit mirror is secured to the wall above the wainscot using a wall cleat. Paint is specified for the wall above the wainscot and the scheduled ceiling, while sensor faucets and soap dispensers are coordinated per mechanical, electrical, and plumbing drawings with attention to ADA compliance.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
