A pedestrian security access arrangement consists of a central turnstile, an adjacent pedestrian gate with a swing clearance arc, and nearby intercom and card reader stations. The assembly is anchored to a concrete substrate shown with standard hatching. The layout provides controlled access paths and device positioning for security checkpoints.
5/ 0-DR-A-040002 INTERCOM AND CARD READER STATION TURNSTILE PEDESTRIAN GATE INTERCOM AND CARD READER STATION
