A-D2QMJ — Entry Canopy Gutter / Edge

Architectural · A-D2QMJ

Entry Canopy Gutter / Edge

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.12
Discipline: Architectural

Materials

Membrane / Roofing Metal (misc.)Steel

Elements

Anchors / Embeds Canopies Connections / Plates Drainage Entrances Roofs Waterproofing / Flashing

Connections

Bolted Connection Welded Connection

Text on the drawing

SHEET METAL GUTTER AND FLASHING CHANNEL PER STRUCTURAL STEEL ANGLE 3" MEMBRANE ROOFING R3
