A-D2MZJ — Conduit Sleeve Floor Fire Pnetration Detail

Architectural · A-D2MZJ

Conduit Sleeve Floor Fire Pnetration Detail

Units: imperial
Sheet: RA-T2.1.2
Discipline: Architectural

Materials

Elements

Anchors / Embeds Floors / Slabs

Text on the drawing

SECTION A A 4" ID RGS CONDUIT FIRESTOP MATERIAL 5" ID RGS SLEEVE FIRESTOP MATERIAL 5" ID RGS SLEEVE TYP. FOUR CONCRETE ANCHORS FINISHED CONCRETE FLOOR SLAB 1" ABOVE SLAB 4" ID RGS CONDUIT
