An acrylic signage plate is attached to the wall assembly with brass coated magnetic standoffs. A magnetic bar is routed into the plywood support board to secure the panel. The brass sheet is attached to the plywood substrate, which is mounted to blocking beyond.
MAGNETIC BAR ROUTED INTO PLYWOOD SUPPORT BOARD ARCYLIC SIGNAGE PLATE, ATTACHED WITH BRASS COATED MAGNETIC STANDOFFS BRASS SHEET, ATTACHED TO PLYWOOD SUBSTRATE, MOUNTED TO BLOCKING BEYOND
