An exterior wood door rests on an aluminum threshold and a pressure-treated wood sill supported by a concrete foundation. Flexible flashing, an ethylene propylene diene monomer sill plate gasket, and felt with sealant create a weather-resistant expansion joint at the transition to the exterior sidewalk. The interior floor features marmoleum flooring over a hydronic heating system, insulation, and a felt expansion joint. Sill anchors with countersunk fasteners secure the assembly to the concrete foundation.
SORPETALER WOOD DOOR, SEE DOOR SCHEDULE ALUMINUM THRESHOLD SHIM FLEXIBLE FLASHING PT WOOD SILL EPDM SILL PLATE GASKET FELT AND SEALANT EXPANSION JOINT EXT. SIDEWALK, SCD CONC. FOUNDATION SSD SILL ANCHOR W/ COUNTER SUNK FASTENERS, SSD INSULATION HYDRONIC SYSTEM MARMOLEUM FLOORING FELT EXPANSION JOINT
