A tapered cruciform column end passes through a soffit assembly, terminating near the bottom of a mullion cap and a DMG-1 soffit panel above GL-3 glazing. The intersection coordinates the structural column profile with the architectural ceiling and storefront framing components.
A 5 A.1 DMG-1 SOFFIT BOTTOM OF MULLION CAP TAPERED CRUCIFORM END OF COLUMN THROUGH SOFFIT GL-3 A A 5 3
