A twenty-two gauge Kynar-coated metal downspout is anchored to the exterior wall using one-and-one-half-inch wide by twenty-two gauge double-fold Kynar-coated downspout straps spaced at five feet on center. Gasketed Tapcon fasteners secure the brackets to match the downspout finish. Color-matched pop rivets join the assembly components, and a Pittsburgh lock secures the downspout seam.
1 12 " WIDE x22 GA. DOUBLE FOLD KYNAR COATED DOWNSPOUT STRAPS @ 5'-0" TO MATCH DOWNSPOUTS GASKETED TAPCON FASTENERS TO MATCH BRACKETS 22 GA. KYNAR COATED MTL. DOWNSPOUT COLOR-MATCHED POP RIVETS PITTSBURG LOCK
