A 16-gauge Unistrut P2000 channel measuring 3 feet 6 inches long is surface mounted and secured using number 10 Hilti Kwik-Pro self-drilling screws. A total of six screws are installed typically, complying with ICC ESR-2196. A vertical support structure hangs from the channel with a maximum load capacity of 300 pounds.
