Suspended ceiling grid terminates at an attached wall angle with a seven-eighths inch dimension and a BERC2 clip. A vertical hanger wire supports the main runner with a maximum spacing of eight inches.
8" MAX. 7/8" BERC2 SECTION AT ATTACHED WALL
