An aluminum structural silicone glazed mullion supports vision glass above a curtain wall door head, with variable mullion depth measuring seven inches at low span and nine and one-quarter inches at high span. A dimension point establishes reference to the face of glass. The door assembly is sized per schedule below the head framing.
DIM. PT. F.O.G. CW DOOR HEAD 1/2" 1" 1/2" CW DOOR PER SCHEDULE VISION GLASS AL. SSG MULLION 7" AT LOW SPAN 9 1/4" AT HIGH SPAN 5"
