A hollow metal door frame connects to a double-studded wall jamb and accommodates a swinging door. The gap between the frame and the adjacent pre-engineered metal building siding is sealed with backer rod and sealant. A frame anchor secures the metal door frame into the double-studded jamb assembly.
HOLLOW METAL DOOR FRAME PEMB SIDING BACKER ROD AND SEALANT DOUBLE STUDED JAMB BACKER ROD AND SEALANT DOOR FRAME ANCHOR
