This plan detail shows a reinforced concrete wall panel intersecting a thickened pier with a thickness sized per the elevation. Vertical reinforcing bars are placed per the schedule and elevation, with edge bars bent at the panel edge. Number 4 ties are spaced at six inches on center full height around the pier. A standard three-quarter inch concrete cover is maintained typically.
PLAN VIEW t SEE ELEV THICKENED PIER SEE PANEL ELEV BEND BAR AT PANEL EDGE REINF PER ELEVATION REINF PER SCHEDULE 3/4" COVER (TYP) #4 TIES @ 6"OC FULL HEIGHT
