A concrete masonry unit wall intersects a structural concrete wall, terminating with a CMU end block that is fully grouted solid at all vertical reinforcement locations. A shop primed dovetail slot runs continuously along the intersection of the walls. A three-eighths inch neoprene sponge compressible filler with sealant on both sides is provided at the joint gap.
NOTE: TYPICAL DETAIL FOR ALL INTERIOR TO INTERIOR OR INTERIOR TO EXTERIOR WALL INTERSECTIONS CMU END BLOCK GROUT SOLID AT ALL VERTICAL REINFORCEMENT MIN 0' - 0 3/8" STRUCTURAL CONCRETE PANEL CMU WALL 3/8" NEOPRENE SPONGE COMPRESSIBLE FILLER W/ SEALANT BOTH SIDES, TYP. SHOP PRIMED DOVETAIL SLOT CONTINUOUS @ INTERSECTION OF ALL CMU WALLS (TYP.) INTERIOR EXTERIOR AWP-1
