Storefront head and sill assembly mounted to a concrete beam and concrete masonry unit wall, incorporating a manufacturer glazing system, sealant and backer rod, gypsum board on metal studs, and an aluminum threshold at the glass entry door. The head condition anchors the aluminum framing below a concrete beam and adjacent gypsum board partitions, sealed with sealant and backer rod. The sill condition bears on a six by eight by eight inch concrete masonry unit wall and finished floor, featuring an aluminum threshold at the glass entry door.
ALIGN ALIGN ALIGN S E E E L E V A T I O N S E E E L E V A T I O N LINE OF FINISHED FLOOR 6" X 8" X 8" CMU GLAZING SYSTEM BY MNFR. GYP BOARD ON METAL STUD SEALANT AND BACKER ROD GLAZING SYSTEM BY MNFR. ELEVATOR LOBBY SEALANT AND BACKER ROD ALUMINUM THRESHOLD GLASS ENTRY DOOR. GLAZING SYSTEM BY MNFR. LINE OF FINISHED FLOOR GLASS ENTRY DOOR ELEVATOR LOBBY GLAZING SYSTEM BY MNFR. GYP BOARD ON METAL STUD SEALANT AND BACKER ROD CONCRETE BEAM
