A two-inch wide marble threshold is set in an epoxy mortar bed designated as THS-1 with a maximum bevel slope of one to two. The threshold transitions between adjacent tile flooring assemblies featuring tile waterproofing and specific vertical dimensions including a 1-1/2 inch total thickness and 1-3/8 inch sub-layer height. A door frame assembly bears directly above the central marble threshold with fastening hardware anchored into the floor.
2" RSF-# CTW-# 3/4" 1 1/2" 1 3/8" 1/8" MAX 5/8" 3/4" TILE WATERPROOFING MARBLE THRESHOLD SET IN EPOXY MORTAR THS-1 MAXIMUM SLOPE OF BEVEL 1:2 1/8" A
