Vertical tongue-and-groove Plyboo wood flooring is installed over a partition wall type defined in the schedule with type 2 backing. The wall cladding terminates below a gypsum board ceiling soffit with a quarter-inch joint clearance. Metal stud framing supports the partition assembly with batt insulation.
PARTITION PER SCHEDULE T&G PLYBOO WOOD FLOORING; INSTALLED VERTICALLY GYP. BOARD SOFFIT; SEE RCP 1/4" TYPE 2 BACKING; SEE 2/A9.20
