A 45-degree angled parking stall features a width of nine feet and a length of eighteen feet, delineated by four-inch-wide yellow stripes spaced at two-foot intervals. Precast concrete auto wheel stops are positioned one foot four inches from the end of the stall where required by site plans or project notes. Adjacent spaces provide standard nine-foot clearance dimensions.
L 45* END OF STALL END OF STALL 1 ’— 4' f ] AUTO WHEEL STOP (WHEN REQUIRED PER DETAIL NOTE 1 F/6.3 OR WHEN DEPICTED ON SITE PLAN) PER DETAIL M/C6.3 2’—0 18’—0 4” WIDE YELLOW STRIPES 9’—0 9’—0
