An acoustically rated partition receives a three-quarter-inch plywood wall panel designated as WP-5, secured via a panel clip system. A one-eighth-inch aluminum bottom edge trim finishes the panel termination above a four-inch wall base. All penetrations in the partition are sealed per the schedule.
ACOUSTICALLY RATED PARTITION PER PLAN AND AS SCHEDULED - SEAL AROUND ALL PENETRATIONS WHERE OCCUR 4" 1/8" 1/8" ALUMINUM BOTTOM EDGE TRIM WITH PANEL CLIP SYSTEM 3/4" PLYWOOD WALL BASE PER SCHEDULE WP-5
