This document outlines the water source information, pressure available, and design analysis for Building 4 point of connection B. The water meter size is 1 and 1/2 inches with a flow available of 40.32 gallons per minute and a static pressure of 67.00 PSI. Service line details indicate a 1 and 1/2 inch size with a 20 foot length, resulting in an available pressure of 64.00 PSI. The design analysis calculates station flows, friction losses, fitting losses, and residual pressure available at 8.52 gallons per minute. Detailed critical station calculations account for design pressure, valve losses, backflow losses, and water meter losses to determine final residual pressure.
