Panels V1 and W2 align at a structural steel column with precise dimensional layout and corner radii. The layout includes a 125.00-degree angle segment with 6-inch radii at the tangent points. Dimensions establish the spatial relationship between the panel profile and the center opening on the steel column.
TANGENT POINT CENTER OPENING ON COLUMN STEEL COLUMN 4 ' - 5 3 / 4 " 2 1 / 2 " 1 ' - 4 1 / 2 " 8 1 / 2 " 2 1 / 2 " 4 7 / 8 " 1 ' - 5 3 / 8 " 4 7 / 8 " 1 ' - 4 7 / 8 " 1 1 " R 6 " R 6 " TANGENT POINTS 1 2 5 . 0 0 °
