Jamb condition for a steel sectional door with a protective steel guard. A three-eighths-inch bent plate jamb guard extends up to four feet and is secured with one-half-inch diameter wedge anchors spaced at twenty-four inches on center. The guard is finished with two coats of safety yellow gloss enamel paint provided by the steel fabricator. An insulated three-inch heavy-duty steel track supports the sectional door, positioned with a dead bolt latch located six inches above the top of the jamb guard. Weather seal is applied all around the perimeter to maintain weather-tightness.
VARIES, SEE PANEL NOTES 1" 4" 4" 6" 1/2" DIA. WEDGE ANCHORS @ 24" O.C. 3/8" BENT PLATE JAMB GAURD TO +4'-0" BY STEEL FABRICATOR. PAINT SAFETY YELLOW (2) COATS GLOSS ENAMEL. 3" HEAVY DUTY TRACK STEEL SECTIONAL DOOR (INSULATED) LOCATE DEAD BOLT LATCH 6" ABOVE JAMB GUARD. WEATHER SEAL, ALL AROUND 1 1/2" = 1'-0" A531 8 ENTRY THRESHOLD DETAIL (STOREFRONT)
