A resilient floor transitions to a finished concrete floor slab at a door frame with a rubber transition strip aligned to the edge of the door frame. The jamb width varies with a maximum height clearance dimension of 0'-0 1/4" at the threshold. The door and resilient flooring are specified per schedule above the finished floor datum.
RUBBER TRANSITION STRIP TO ALIGN WITH EDGE OF DOOR FRAME VARIES JAMB WIDTH 0' - 0 1/4" MAX RESILISENT FLOOR PER SCHEDULE FINISHED CONCRETE DOOR PER SCHEDULE DOOR FRAME BEYOND FF
