An eleven-gauge steel plate is detailed with an overall length of 3.50 inches and a width of 1.56 inches with a plus-zero minus-zero-point-zero-ten tolerance. The profile features formed flanges measuring 0.75 inches deep with inside corner radii of R0.13. Two paired cutouts and clearance slots of 0.25 and 0.13 inches are dimensioned symmetrically. Critical hole-to-edge spacing is maintained at 1.300 plus-or-minus 0.005 inches.
(.1196) 11GA 0.63 1.00 2x 0.25(2PL) 2x 0.13(2PL) 1.56 +0.000 1.300±.005 2x R0.13 2x 0.75 3.50 T I
