The assembly is supported by a 12 gauge vertical hanger wire extending to the underside of the structural framing above. Four horizontal 12 gauge seismic splay brace wires are anchored with a minimum of four turns per wire. A double metal stud compression strut is installed with spacing up to 16 inches on center, tied back to a 1-1/2 inch by 16 gauge runner channel spaced at 4 feet on center. The ceiling grid incorporates 7/8 inch by 26 gauge hat channels supporting gypsum board, fastened with two 12-14 self-tapping metal screws at the stud to T-bar connection.
℄ NOTE: REFER TO DETAIL --/--.-- FOR COMPRESSION STRUT SCHEDULE 45°±10° 1 1/2" 16" O.C. MAX. 2" CONTINUE 12 GA. VERTICAL HANGER WIRE TO UNDERSIDE OF STRUCTURAL. REFER TO DETAIL --/---- (4) HORIZONTAL 12 GA. SEISMIC SPLAY BRACE WIRE WITH MIN. 4 TURNS PER WIRE WITHIN 1-1/2" DOUBLE COMPRESSION STRUT. REFER TO SCHEDULE METAL STUD COMPRESSION STRUT. REFER TO SCHEDULE FOR MAX. HEIGHT (2) 12-14 SMS AT STUD TO T-BAR 1-1/2" x 16 GA. RUNNER CHANNEL @ 4'-0" O.C. 7/8" 26 GA. HAT CHANNEL GYP. BD.
