A two-and-a-half-inch outer diameter steel pipe top rail sits above a vertical pipe railing with an integrated one-and-a-half-inch outer diameter steel pipe handrail. One-half-inch diameter steel rods and a plate infill connect the handrail assembly to the half-inch steel flat bar posts. The posts anchor to the stair stringer adjacent to the stair treads. The handrail is positioned three feet above the finished floor.
2-1/2" O.D. STEEL PIPE TOP RAIL VERTICAL PIPE RAILING 1/2" STEEL FLAT BAR HANDRAIL SUPPORT PLATE INFILL FOR HANDRAIL ATTACHMENT 1-1/2" O.D. STEEL PIPE HANDRAIL 1/2" STEEL FLAT BAR POST STAIR STRINGER STAIR TREAD 1/2" DIA STEEL ROD 3'-0" A.F.F. 1'-0" MIN. NOT INCL. ROUNDED END OF HANDRAIL 11 1/2" 11"
