The hollow metal door frame is set adjacent to a concrete masonry unit block wall backed by cement board and an exterior masonry veneer. Shims are installed as required between the frame and wall assembly. A continuous sealant and backer rod are applied at the joint between the frame and the adjacent masonry.
EXTERIOR MASONRY VENEER - SEE EXTERIOR ELEVATIONS CMU BLOCK HALLOW METAL FRAME HALLOW METAL DOOR - SEE DOOR SCHEDULE CONTINUOUS SEALANT AND BACKER ROD SHIM AS REQUIRED CEMENT BOARD MASONRY VENEER MORTAR
