A hollow metal door frame is plumbed with shims against a concrete masonry unit veneer wall assembly, integrating an air barrier installed continuously into the jamb. A twenty-two gauge bent metal jamb trim matches the adjacent metal panel profile. A typical corner bead finishes the edge condition at the wall finish.
E-1 / A310 HM DOOR, RE: DOOR SCHEDULE SHIM CORNER BEAD - TYP. INSTALL AIR BARRIER INTO JAMB 8" 6" 3" 6" 22 GA. METAL JAMB, BENT, TO MATCH METAL PANEL
