Architectural · A-BVCNX

Plan Detail Room 115

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Elements

Floors / Slabs Partitions Walls

Text on the drawing

9 EXTERIOR WALL ASSEMBLY, RE: FLOOR PLANS ACOUSTIC/FIRE RATED WALL ASSEMBLY, RE: FLOOR PLANS WALL ASSEMBLY RE: FLOOR PLANS 5
