A 1-1/2 inch outside diameter steel pipe handrail and 5/8 inch outside diameter steel pipe intermediate railings are supported by a 1-1/2 inch outside diameter handrail support. The handrail and intermediate railings align with the stair stringer and a closer plate, requiring a field splice at the termination point that must be welded and ground smooth. The stair nosing is located at the tread, and a 2 inch wide contrasting color warning stripe is applied to the top and bottom treads of the interior stair. Intermediate railing spacing is 3 inches from the handrail, with central spacing determined per plan.
Text on the drawing
DN UP STAIR NOSING, TYP. STAIR STRINGER, BELOW, TYP. 1" O.D. STL. PIPE INTERMEDIATE RAILING, TYP. 1-1/2" O.D. STL. PIPE HANRAIL, TYP. 5/8" O.D. STL. PIPE INTERMEDIATE RAILING, TYP. EDGE OF STRINGER CLOSER PLATE 1-1/2" O.D. HANDRAIL SUPPORT, TYP. 2" WIDE, CONTRASTING COLOR WARNING STRIPE, TYP. AT TOP & BOTTOM TREADS FOR INTERIOR STAIRS. TYP 1' - 3" 1 1/2" 3" PER PLAN 3" FIELD SPLICE, WELD & GRIND SMOOTH (FIELD TRIMMING MAY BE REQ'D.) SCALE: 1 1/2" = 1'-0" 53 INSIDE HANDRAIL ON SWITCHBACK STAIRS
